C-Reader Passport & ID scanners scans and reads ID documents.

It is very usefull in hotels, banks, embassies, travel and employment agencies.

Very quick, accurate and time saving units which also checks passports and ID cards on authentication.

Please contact us to help you with your ID reader application.

Combo Smart Flyergratis2



Your specialist in Passport, ID and Driving License all-in custom solutions.

Our website C-Reader.com is still in development. But our company delivers more than 10 years all kind of ID/Passport/Driving License projects.

Please contact us for your specific ID Reader project, so we will help you.

Passport / ID-Scanner

C-Reader PRMc Multi-Reader is a compact all-in-one solution for document reading (passport, ID card)  and verifying. The built-in digital signal processor unit (DSP) significantly speeds up image-processing, thus efficiently reduces queuing time.
Main advantages of C-Reader PRMc Multireaders
World leader OCR algorithm: The C-Reader passport scanners use the high performance Optical Character Recognition (OCR) algorithm that has been developed.
More reliable and faster operation: passport data extraction is now all-time effective. We equip every single PRMc passport scanner with high performance DSP (Digital Signal Processor) which results in better and more accurate image recognition.
Fast MRZ data reading: the C-Reader passport scanner is an ideal solution for MRZ data reading of passports. The image taking process and the MRZ reading is fast and reliable and they both take less than a second together.
Excellent image quality: the built-in cameras in the new C-Reader passport scanner take high resolution (2048x1536 pixel, 24bit colour depth) images of documents that are put into the device. These high resolution pictures are taken by the cameras with every illumination separately. Upon request we can also deliver the devices with 600DPI or even 1200DPI optical resolution support for specific parts of the image.
Flexibility: We accepts production requests for smaller quantities which make it possible to meet your  requirements in the most flexible way. If you do not find the device that you are looking for, we are ready to modify our devices according to your needs. We are able to manufacture custom devices: you may request the devices with different color case, other device options, custom design, different configuration etc.

Integration Possibilities
The new C-Reader document scanners are a smart combination of traditional document scanning devices: fast, accurate and reliable machines that effectively help your daily business with performance and stylish look. You can read every, standard travel documents and ePassports with the new C-Reader.

Application Opportunities
Our system integrator partners usually turn to us in order to build a high quality, complex document reading system. We developed automatic document reading and checking products and applications for over 10 years.

Our passport reading products are working in several countries at
- Border crossing points
- Hotels
- International shipping routes
- International lines

Technical Specifications of C-Reader
C-Reader PRMc ID-Reader is a compact all-in-one solution for document reading and verifying. All C-Reader PRMc passport scanners use the high performance optical character recognition (OCR) algorithm that has been developed. The built-in digital signal processor unit (DSP) significantly speeds up image-processing, thus efficiently reduces queuing time.

C-Reader PRMc document scanners are a smart combination of traditional document scanning devices: fast, accurate and reliable devices that effectively help your daily business with performance and stylish look.

The C-Reader PRMc series
PRMc 123 One camera, Visible + IR illumination
PRMc 223 Two cameras, Visible + IR illumination
PRMc 233 Two cameras, Visible + IR + UV illumination

Available options for C-Reader
RFID module (type R)
Smard Card module (type S)
700PPi photo camera (type P)
Extended document window 130x100mm (type E)
Built-in USB hub
Flip-top cover

Optical specifications
Image sensor 3 Megapixel
Image resolution 400 DPI
Face image resolution 700 DPI (available in type P devices)
Image color depth 24 bits/pixels [RGB, 8bits/pixels (infra image)]
Hardware units
Internal memory Storing factory calibration
Firmware upgrade Automatic
Built in DSP data processing unit
Mechanical Data
Size with cover 213 x 173 x 179 mm (8.39" x 6.81" x 7.08")
Window size 130 mm x 98 mm (5.12" x 3.86")
Case ABS plastic on metal base
Window glass 4mm tempered glass
Operating temperature +5°C to +45 °C (41°F to 113°F)
Operating humidity 0-95% (non-condensing)
Weight 2.2kg - 2.4kg (4.85-5.29lb) depending on the model
No moving parts
Kensington security slot

Other specifications
Compliances CE, FCC, RoHS, IEC62471
Interface USB 2.0
3pcs free USB ports Available in type U devices
Number of status LEDs 3 programmable
Power External power supply included (100-240V AC, 50/60Hz)

RFID module
Single step readin
DUAL RFID antenna
RFID chip is detected in any position within the passport
Support all ISO14443 A/B chip types
Active/passive authentication, BAC, EAC
RFID data is read with the highest possible speed supported by the chip

Smart card module
Support ISO 7816 & EMV2 2000 Level 1 standards

Advanced Document Authentication Module (ADAM)
MRZ checksum validation
MRZ vs. VIZ comparing Optional
Printed MRZ comparing to MRZ stored in RFID chip
Printed face photo comparing to photo stored in RFID chip -DG2- Optional
Expiry date check
B900 ink check
UV dull paper check (in case of devices with UV light)
Automatic pattern matching under Normal, UV, IR light Optional, ask for details
Authentication methods with Photo Camera (type P devices)
Photo substitution check Manual
JURA IPI decoding - Optional
GSSC VIPhotoTM decoding - Optional
Background printing check - Manual
Microprinting check - Manual

Software Development Kit (SDK)
Supported OS Windows 7 (32/64bit)
Windows Vista (32/64bit)
Windows XP (32/64bit)
Windows 2003 (32/64bit)
Linux (optional, ask for details)
Programing languages C/ C++ C#
Visual Basic 6.0 / Delphi / VB.NET / Java
MRZ OCR reading ICAO 9303
VIZ OCR reading Zones defineable by user
2D barcode reading PDF 417
Data Matrix / QR Code / Aztec Code
1D barcode reading EAN8, EAN13, Code39, Code128.
Interleaved 2 of 5
Image format BMP / JPG / JPG2000 / PNG
Extended High Colour Fidelity (XCF) Automatic colour calibration
Outstading delta E value (ref. Q-60R2 Kodak Target)

We attach an all-around Software Development Kit (SDK) and drivers on a CD-ROM therefore you can easily design and build your own, fully customized document scanning system to your clients.

The attached SDK supports numerous Operation Systems and programming languages, as a result you can integrate our C-Reader into your system seamlessly.
